ASRock X570 EXTREME4 *[FCLGA1200]* ATX Motherboard : 1 x DDR4 Slot, 2 x PCIe 3.0 x16 Slots, 8 x SATA III Slots 7.1-Channel Audio

$222

SOLD OUTClick for similar items

Don't miss our Special Coupons:
BFTG2110 - $10 (Order above $250)
BFTG2120 - $20 (Order above $600)
BFTG2130 - $30 (Order above $800)
BFTG2140 - $40 (Order above $999)
Offer ends in
About this product
SKU# X570 EXTREME4 | Item# 153294
Warranty: 1 Year Warranty
Condition: New Factory Sealed
Packaging: Retail Box
Minimum order quantity (MOQ): 1
Images and specifications are for reference only
Usually ships within 7-10 business days
Special order item, not eligible for return/cancellation execpt for More info
SKU: X570 EXTREME4 Category:

Additional information

REVOLUTIONARY X570 MOTHERBOARDS :
Your PC Transformed
Style . More reliable. Design that delivers.

STEEL SLOT WITH NEW-GEN PCI EXPRESS 4.0
The next generation PCI Express 4.0 is capable of performing twice the speed compared to previous 3rd generation. ASRock’s exclusive Steel Slot with extra anchor points are revolutionary added to ensure signal stability and also making sure heavy graphics cards to be well-installed in the PCI-E slot safely.

Dual Hyper M.2 For SSD
Supports the next generation PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.

RULE YOUR OWN LIGHTING WAY – POLYCHROME RGB
ASRock motherboards deliver stunning performance and superior aesthetics to rule your own colorful lighting way! ASRock offers a very comprehensive control to perform the built-in RGB LEDs or the connected LED strips, CPU fans, coolers, chassis and any RGB devices smoothly. Devices can be synchronized across the Polychrome RGB Sync-certified accessories as well.

Flexible Integrated I/O Shield
Unlike most so called pre-mounted I/O shield that is only decorated with fancy color schemes. We reserve more tolerance space and allow IO shield is adjustable when installing, thus fitting chassis perfectly without any mechanical issue.

10 POWER PHASE DESIGN
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.

Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.

Dual USB 3.2 Gen2 (Type-A + Type-C)
This motherboard has a pair of onboard Type-A and Type-C USB 3.2 Gen2 ports built on the rear i/o for supporting next generation USB 3.2 Gen2 devices and to deliver up to 10 Gbps data transfer rates.

Front USB 3.2 Gen1 Type-C
Front USB 3.2 Gen1 Type-C header delivers up to 5 Gbps data transfer rate and next generation reversible USB design to the front panel of computer case.

PREMIUM 60A POWER CHOKE
ASRock’s premium 60A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.

Post Status Checker
An easy troubleshooting tool that shows the CPU / DRAM / VGA / BOOT operation every time you start up the system. Post Status Checker is an fast and easy way to identify the source of the problem.

Purity Sound 4
It’s time to enjoy the most purified audio performance with ultra high definition. Purity Sound4 is a combination of several hardware, software audio solutions. 7.1 CH HD audio with the latest Realtek ALC1220 audio codec, individual PCB layers for R/L audio channel, 120dB SNR DAC and other technologies to deliver the crispest sound effects.

Processor manufacturerAMD
Processor socketSocket AM4
Compatible processor series2nd Generation AMD Ryzen™ 3, AMD Ryzen 3 3rd Gen, 2nd Generation AMD Ryzen™ 5, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9
Supported memory typesDDR4-SDRAM
Number of memory slots4
Maximum internal memory128 GB
Memory slots typeDIMM
Memory channelsDual-channel
ECCY
Non-ECCY
Supported memory clock speeds2133,2400,2667,2933,3200,3466,3600,4133,4200,4266,4300,4400 MHz
Unbuffered memoryY
Supported storage drive interfacesM.2,PCI Express 3.0,SATA III
Maximum resolution4096 x 2160 pixels
HDCPY
DirectX version12.0
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of SATA III connectors8
Front panel audio connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of chassis fan connectors4
Peripheral (Molex) power connectors (4-pin)1
EPS power connector (8-pin)Y
Thunderbolt headers1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
PS/2 ports quantity1
HDMI version2.0
S/PDIF out portY
WiFi-AP antenna jack2
Ethernet LANY
Ethernet interface typeGigabit Ethernet
LAN controllerIntel® I211-AT
Wake-on-LAN readyY
Component forPC
Motherboard form factorATX
Motherboard chipset familyAMD
Motherboard chipsetAMD X570
Audio output channels7.1 channels
Audio chipRealtek ALC1220
Windows operating systems supportedWindows 10 x64
CertificationFCC, CE, ErP/EuP
Number of M.2 (M) slots2
BIOS typeUEFI AMI
BIOS memory size256 Mbit
ACPI version5.1
System Management BIOS (SMBIOS) version2.3
Width12" (305 mm)
Depth9.61" (244 mm)
Number of M.2 (E) slots1
