MSI Cubi B0A8 MFF Desktop Core i7-1255U NO OS BLACK 824142310328



We still have a selection of similar available alternatives, click to check them out

Extra 5% off with coupon:
Ends in:
About this product
SKU# CUBI512M016B | Item# 394464
Warranty: 1 Year Manufacturer Warranty
Condition: New Factory Sealed
Packaging: Retail Box
Minimum order quantity (MOQ): 1
Images and specifications are for reference only
Usually ships within 7-10 business days
Special order item, not eligible for return/cancellation execpt for More info
SKU: CUBI512M016B Category:

Additional information

Be Your window To The World
We always focus on how to improve the efficiency, stability and flexibility for users in any kinds of situations.

Small But Powerful
Bring it home when you need without any inconvenience that it can be your mini PC and your portable storage device.

Cubi 5 allows you to enjoy the best experience of watching movie with your family or attending online conference call while working from home or learning professional tasks at home.

Thunderbolt™ 4 brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all – delivering the fastest, most versatile connection to any dock, display, or data device & NAS.
Embracing a wide array of interface compatibilities so that you can edit, collaborate and share seamlessly

With HDMI™, DP, and Thunderbolt 4, Cubi 5 allows you to extend to three monitors to preview your E-commerce content & data at home or in the office, enhancing your efficiency.

MSI Cloud Center

Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS device faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.

The MSI Center takes optimization to the next level with easily adjustable system modes; it helps to prioritize & allocate the resource on your hand to accelerate the performance of those software which you work with everyday.

Equips up to 12th Gen Intel® Core™ i7 processor with 10 cores and 12 threads, delivering computing capability and keeping you in the flow, wherever you go. Also, enjoy more detailed, immersive viewing experience with Intel® Iris® Xe Graphics.

Wi-Fi 6E puts more emphasis on transmission security and improves the signal between the interference problem can also be connected to more devices at the same time, thereby meeting the trend of higher and higher data transmission bandwidth requirements with speed up to 2.4Gbps.

USB 3.2 GEN 2 Type A
With data transfer speeds up to 10Gbps, dual USB 3.2 Gen 2 Type A ports in the front I/O offer twice the bandwidth of the older USB 3.1 Gen 1 Type A ports, effectively halving any data delay or waiting time.

More than Dual LAN, the best way to secure your data and prevent the Hacker

With the Dual LAN Design, the Cubi 5 will always be your backup and support
the Internet/Intranet dual network environments.

Working on NAS? Connect and rapidly transfer data over a network with the high-bandwidth and low-latency 2.5Gbps Ethernet LAN. Integrated with the exclusive MSI LAN Manager, it prioritizes latency-sensitive application and allows you to take control of their experience.

FW TPM (Trusted Platform Module) technology is designed to provide hardware-based, security-related functions. You can store your sensitive data & passwords by encryption keys for advanced security.

Users can easily upgrade two SO-DIMM, one M.2 SSD or one 2.5” HDD/SSD by disassembling the cover. Made Cubi 5 an even flexible desktop and also reduce the time wasting on upgrading.

VESA Mountable design allows users to hook Cubi 5 up anywhere you like or mount it with MSI PRO MP243 Series . Not only improve the flexibility of using Cubi 5, but also let users make good use of their space at home or at office.

With a complete array of I/O ports, it can connect all devices you need and connect many devices at the same time so you can multi-task with those devises to make you work more efficiently and of course you won’t need an adaptor or a dock.

Successful & Stylish B2B projects
Over the past years, MSI has successfully supported Countless of commercial projects, including government tenders, restaurant & hotel facilitation, shopping mall navigation projects, school & university developments and professional office projects.

Cubi 5 12M
Windows 11 Home
– MSI recommends Windows 11 Pro for business
Up to 12th Gen Intel® Core™ i7 Processors
Support up to 8K UHD Display
Support three displays that allow you to see more and do more
Thunderbolt 4 delivers the fastest, most versatile connection to any dock, display, or data device & NAS
Dual LAN: the best way to back up your file / secure data and prevent the hacker (with MSI exclusive BIOS)
Get all the performance benefits from USB 3.2 Gen 2 and enjoy the best data transmission experience
Experience 75% lower latency with WiFi 6E technology(optional)
FW TPM design secures your confidential data with encryption keys
Supports standard VESA-mount
Barebones versions are also available

Processor familyIntel® Core™ i7
Processor manufacturerIntel
Processor modeli7-1255U
Processor frequency3.5 GHz
Processor generation12th gen Intel® Core™ i7
Processor cores10
Performance cores2
Efficient cores8
Efficient-core Max Turbo Frequency3.5 GHz
Performance-core Max Turbo Frequency4.7 GHz
Processor cache12 MB
Processor cache typeSmart Cache
Processor threads12
Configurable TDP-down12 W
Number of processors installed1
Processor base power15 W
Maximum turbo power55 W
Maximum internal memory64 GB
Internal memory typeDDR4-SDRAM
Memory slots2x SO-DIMM
Memory clock speed2666 MHz
Optical drive typeN
Storage mediaHDD+SSD
Number of storage drives supported2
HDD interfaceSATA
SSD interfaceM.2, SATA
Discrete graphics cardN
On-board graphics cardY
Discrete graphics card modelNot available
On-board graphics card modelIntel® UHD Graphics
On-board graphics card familyIntel® UHD Graphics
Ethernet LANY
Ethernet LAN data rates1000 Mbit/s
LAN controllerRealtek RTL8111H, Realtek RTL8125-BG, Realtek RTL8125-CG
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Wi-Fi standardsWi-Fi 6E (802.11ax)
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
HDMI ports quantity1
USB Type-C DisplayPort Alternate ModeY
Thunderbolt 4 ports quantity4
HDMI version2.0
DisplayPorts quantity1
DisplayPort version1.4
Ethernet LAN (RJ-45) ports2
Combo headphone/mic portY
DC-in jackY
Product colorBlack, White
VESA mountingY
Number of 2.5" bays1
Product typeWorkstation
Market positioningBusiness
Motherboard chipsetIntel SoC
Trusted Platform Module (TPM)Y
Operating system installedN
CPU configuration (max)1
Power supply65 W
Width4.88" (124 mm)
Depth4.88" (124 mm)
Height2.09" (53 mm)
Weight19.3 oz (548 g)
Display includedN
