MSI Cubi B0A8 MFF Desktop Core i5-1235U NO OS BLACK 824142310168
$522
SOLD OUT
We still have a selection of similar available alternatives, click to check them out
BLACKFRIDAY
Ends in:
Additional information
Be Your window To The World
We always focus on how to improve the efficiency, stability and flexibility for users in any kinds of situations.
Small But Powerful
Bring it home when you need without any inconvenience that it can be your mini PC and your portable storage device.
SUPPORT UP TO 8K RESOLUTION
Cubi 5 allows you to enjoy the best experience of watching movie with your family or attending online conference call while working from home or learning professional tasks at home.
BOLT TO THE NEXT POWER
Thunderbolt™ 4 brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all – delivering the fastest, most versatile connection to any dock, display, or data device & NAS.
Embracing a wide array of interface compatibilities so that you can edit, collaborate and share seamlessly
SEE MORE, DO MORE
With HDMI™, DP, and Thunderbolt 4, Cubi 5 allows you to extend to three monitors to preview your E-commerce content & data at home or in the office, enhancing your efficiency.
MSI Cloud Center
FAST, SECURE & WIRELESS BACKUP
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS device faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.
MSI CENTER
The MSI Center takes optimization to the next level with easily adjustable system modes; it helps to prioritize & allocate the resource on your hand to accelerate the performance of those software which you work with everyday.
STABLE & POWERFUL
Equips up to 12th Gen Intel® Core™ i7 processor with 10 cores and 12 threads, delivering computing capability and keeping you in the flow, wherever you go. Also, enjoy more detailed, immersive viewing experience with Intel® Iris® Xe Graphics.
WI-FI 6E TECHNOLOGY
Wi-Fi 6E puts more emphasis on transmission security and improves the signal between the interference problem can also be connected to more devices at the same time, thereby meeting the trend of higher and higher data transmission bandwidth requirements with speed up to 2.4Gbps.
USB 3.2 GEN 2 Type A
With data transfer speeds up to 10Gbps, dual USB 3.2 Gen 2 Type A ports in the front I/O offer twice the bandwidth of the older USB 3.1 Gen 1 Type A ports, effectively halving any data delay or waiting time.
DUAL LAN – SECURITY
More than Dual LAN, the best way to secure your data and prevent the Hacker
ALWAYS BE YOUR BACKUP
With the Dual LAN Design, the Cubi 5 will always be your backup and support
the Internet/Intranet dual network environments.
CREATE THROUGH THE 2.5G LAN
Working on NAS? Connect and rapidly transfer data over a network with the high-bandwidth and low-latency 2.5Gbps Ethernet LAN. Integrated with the exclusive MSI LAN Manager, it prioritizes latency-sensitive application and allows you to take control of their experience.
FW TPM SUPPORT
FW TPM (Trusted Platform Module) technology is designed to provide hardware-based, security-related functions. You can store your sensitive data & passwords by encryption keys for advanced security.
EASY MAINTENANCE
Users can easily upgrade two SO-DIMM, one M.2 SSD or one 2.5” HDD/SSD by disassembling the cover. Made Cubi 5 an even flexible desktop and also reduce the time wasting on upgrading.
VESA MOUNT SUPPORT
VESA Mountable design allows users to hook Cubi 5 up anywhere you like or mount it with MSI PRO MP243 Series . Not only improve the flexibility of using Cubi 5, but also let users make good use of their space at home or at office.
VARIOUS IO PORTS
With a complete array of I/O ports, it can connect all devices you need and connect many devices at the same time so you can multi-task with those devises to make you work more efficiently and of course you won’t need an adaptor or a dock.
Successful & Stylish B2B projects
Over the past years, MSI has successfully supported Countless of commercial projects, including government tenders, restaurant & hotel facilitation, shopping mall navigation projects, school & university developments and professional office projects.
Cubi 5 12M
Windows 11 Home
– MSI recommends Windows 11 Pro for business
Up to 12th Gen Intel® Core™ i7 Processors
Support up to 8K UHD Display
Support three displays that allow you to see more and do more
Thunderbolt 4 delivers the fastest, most versatile connection to any dock, display, or data device & NAS
Dual LAN: the best way to back up your file / secure data and prevent the hacker (with MSI exclusive BIOS)
Get all the performance benefits from USB 3.2 Gen 2 and enjoy the best data transmission experience
Experience 75% lower latency with WiFi 6E technology(optional)
FW TPM design secures your confidential data with encryption keys
Supports standard VESA-mount
Barebones versions are also available
Processor family | Intel® Core™ i5 |
Processor manufacturer | Intel |
Processor model | i5-1235U |
Processor frequency | 3.3 GHz |
Processor generation | 12th gen Intel® Core™ i5 |
Processor cores | 10 |
Performance cores | 2 |
Efficient cores | 8 |
Efficient-core Max Turbo Frequency | 3.3 GHz |
Performance-core Max Turbo Frequency | 4.4 GHz |
Processor cache | 12 MB |
Processor cache type | Smart Cache |
Processor threads | 12 |
Configurable TDP-down | 12 W |
Number of processors installed | 1 |
Processor base power | 15 W |
Maximum turbo power | 55 W |
Maximum internal memory | 64 GB |
Internal memory type | DDR4-SDRAM |
Memory slots | 2x SO-DIMM |
Memory clock speed | 2666 MHz |
Optical drive type | N |
Storage media | HDD+SSD |
Number of storage drives supported | 2 |
HDD size | 2.5" |
SSD interface | M.2, PCI Express, SATA |
Discrete graphics card | N |
On-board graphics card | Y |
Discrete graphics card model | Not available |
On-board graphics card model | Intel® UHD Graphics |
On-board graphics card family | Intel® UHD Graphics |
Ethernet LAN | Y |
Wi-Fi | Y |
LAN controller | Realtek RTL8111H, Realtek RTL8125-BG, Realtek RTL8125-CG |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
HDMI ports quantity | 1 |
Thunderbolt 4 ports quantity | 1 |
Intel® Thunderbolt 4 | Y |
HDMI version | 1.4 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.2 |
Ethernet LAN (RJ-45) ports | 2 |
Combo headphone/mic port | Y |
DC-in jack | Y |
Chassis type | Mini PC |
Product color | Black, White |
Number of 2.5" bays | 1 |
Product type | Workstation |
Market positioning | Business |
Trusted Platform Module (TPM) | Y |
Operating system installed | N |
CPU configuration (max) | 1 |
Power supply | 65 W |
Width | 4.88" (124 mm) |
Depth | 4.88" (124 mm) |
Height | 2.09" (53 mm) |
Weight | 19.3 oz (548 g) |
Display included | N |
