Lenovo ThinkSmart Hub 500 ALL-IN-ONE for VIDEO CONFERENCING Core™ i5-7500T 128GB SSD 8GB 11.6″ (1920×1080) TOUCHCREEN WIN10 LoT Enterprise BLACK

$335$402

CyberMonday SALE!
Extra 5% off with coupon:
NEW2024

31 in stock

Eligible for an additional 5% discount!
With coupon code: NEW2025
About this product
SKU# 10V50000US | Item# 512463
Warranty: 1 Year Manufacturer Warranty
Condition: New Factory Sealed
Packaging: Retail Box
Minimum order quantity (MOQ): 1
Images and specifications are for reference only
Usually ships within 2-4 business days
Special order item, not eligible for return/cancellation execpt for More info
SKU: 10V50000US Category: Tag:

Additional information

Because everyone’s time is valuable
Meetings are time consuming enough without trying to get the technology to work properly. The average delay is around 10 minutes, but with the ThinkSmart Hub 500, you can avoid costly late starts. As audio and video is already connected, simply hit one button and everyone can begin collaborating right away.

A better way for teams to work together
A key feature of the ThinkSmart Hub 500 is its eye-catching anti-glare, anti-smudge display. Rotatable through 360°, anyone within arm reach can take and give control instantly, enabling meetings to run more smoothly—and more fairly. There’s also a 3-color LED ring that lets everyone in the room know the status of the call.

Simplify meetings, worldwide
Whether you’re a host or attendee, the ThinkSmart Hub 500 will make your life easier. Designed with small to medium-sized conference rooms in mind, it’s available in 180 countries. That way, everyone in your organization will be familiar with the system wherever your business takes them.

Enhanced security and manageability features
When it comes to security and practicality, the ThinkSmart Hub 500 has it covered. Windows 10 IoT Enterprise provides intelligent enterprise-grade protection, while the Intel vPro processor helps you to maintain remote devices, and the built-in Skype Room Systems app has a universal lockdown feature. Skype for Business is a universal locked-down app. In addition, an innovative cable management door secures physical ports and prevents cables being accidentally disconnected.

Display diagonal11.6"
Display resolution1920 x 1080 pixels
TouchscreenYes
HD typeFull HD
LED backlightYes
Touch technologyMulti-touch
Native aspect ratio16:9
Display brightness300 cd/m²
Display surfaceMatt
Panel typeWVA
Screen shapeFlat
Processor familyIntel® Core™ i5
Processor manufacturerIntel
Processor modeli5-7500T
Processor frequency2.7 GHz
Processor generation7th gen Intel® Core™ i5
Processor cores4
Processor threads4
Processor boost frequency3.3 GHz
Processor cache6 MB
Processor cache typeSmart Cache
System bus rate8 GT/s
Thermal Design Power (TDP)35 W
Configurable TDP-down frequency1.7 GHz
PCI Express slots version3.0
Processor socketLGA 1151 (Socket H4)
Processor lithography14 nm
Processor operating modes64-bit
Bus typeDMI3
Number of QPI links0
Processor codenameKaby Lake
Maximum number of PCI Express lanes16
PCI Express configurations2x8, 1x8+2x4
Tjunction80 °C
Maximum internal memory supported by processor64 GB
Conflict-Free processorYes
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor1333,1600,2133,2400 MHz
Memory channels supported by processorDual
ECC supported by processorNo
Memory voltage supported by processor1.35 V
Internal memory8 GB
Maximum internal memory8 GB
Internal memory typeDDR4-SDRAM
Memory slots2
Memory slots typeSO-DIMM
Memory clock speed2400 MHz
Memory layout (slots x size)2 x 4 GB
Memory form factorDIMM/SO-DIMM
Total storage capacity128 GB
Storage mediaSSD
Optical drive typeNo
Number of SSDs installed1
SSD capacity128 GB
SSD form factorM.2
Card reader integratedNo
Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics cardYes
On-board graphics card modelIntel® HD Graphics 630
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.4
On-board graphics card ID0x5912
Built-in speaker(s)Yes
Number of speakers2
RMS rated power4 W
Built-in microphoneYes
Built-in cameraNo
Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet LANYes
BluetoothYes
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN controller modelIntel Dual Band Wireless-AC 8265
Antenna type1x1
Ethernet LAN data rates10,100,1000 Mbit/s
Bluetooth version4.1
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
HDMI ports quantity3
Ethernet LAN (RJ-45) ports1
Thunderbolt ports quantity0
Thunderbolt 3 ports quantity0
VGA (D-Sub) ports quantity0
Headphone outputs0
Microphone inNo
Combo headphone/mic portYes
Product colorBlack
Product typeAll-in-One PC
Motherboard chipsetIntel® Q270
Trusted Platform Module (TPM)Yes
Operating system installedWindows 10 IoT Enterprise
Operating system architecture64-bit
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Enhanced Intel SpeedStep TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel Clear Video TechnologyYes
Intel® InTru™ 3D TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel Enhanced Halt StateYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Secure KeyYes
Intel TSX-NIYes
Intel Stable Image Platform Program (SIPP)Yes
Intel® OS GuardYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel 64Yes
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0
Scalability1S
CPU configuration (max)1
Embedded options availableYes
Thermal solution specificationPCG 2015A
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Identity Protection Technology version1.00
Intel Stable Image Platform Program (SIPP) version1.00
Intel Secure Key Technology version1.00
Intel Virtualization Technology (VT-x)Yes
Intel TSX-NI version1.00
Processor ARK ID97121
AC adapter power90 W
AC adapter frequency50/60 Hz
AC adapter input voltage100 - 240 V
Pen includedNo
Width (with stand)11" (278.9 mm)
Depth (with stand)7.61" (193.2 mm)
Height (with stand)7.03" (178.4 mm)
Weight (with stand)5.51 lbs (2.5 kg)
Compliance certificatesRoHS
CertificationGREENGUARD, WEEE, ErP Lot 26
Mouse includedNo
Cables includedAC
Drivers includedYes
Power cord includedYes
ManualYes
3DNo
Autonomy modeNo
Detachable displayNo
