Lenovo ThinkCentre M90n-1 Nano Core™ i3-8145U 2.1GHz 128GB SSD 4GB WIN10 Pro Keyboard Mouse BLACK
$214
SOLD OUT
We still have a selection of similar available alternatives, click to check them out
BLACKFRIDAY
Ends in:
Additional information
Go fanless & propel your business
From tapping into the Internet of Things (IoT) to extending legacy systems, the ThinkCentre M90n Nano IoT delivers real flexibility and reliability. With 4G and I/0 Box capabilities, it gives you diverse connectivity and multi-user options. Compact and fanless, it can be housed almost anywhere. Able to handle big data with ease, this reliable system integrator also features first-rate security and durability.
Work smarter, not harder
Increased productivity and better workflow are just two of the ways that the Internet of Things, or IoT, can help an organization. By seamlessly interacting with smart devices and sensors, both near and far, the ThinkCentre M90n Nano IoT lets your business leverage the real benefits of IoT.
Powerful & versatile
Thanks to 8th Gen Intel@ processors, the ThinkCentre M90n Nano IoT performs as fast and reliable as a regular PC—but is only half the size. And with the USB-C port, you have expansion options, too.
Quiet as a mouse, strong as an ox
Being fanless, the ThinkCentre M90n Nano IoT is far quieter than most PCs. So you can tuck it almost anywhere—under a desk, in a cupboard, or on a shelf. What’s more, it meets the most stringent of durability tests (including military standards) and can withstand the harshest of work environments, such as a desert or high altitude.
Here today, here tomorrow
Why rip out legacy systems, when an I/O box can breathe new life into them, quickly and easily? The extra ports and connectivity can enhance your investment and bottom line, too. In addition, you can affix the ThinkCentre M90n Nano IoT to a VESA mount, industrial DIN rail, or any type of bracket in a flash.
IoT-ready & -certified
Designed with the ever-expanding IoT network in mind, the ThinkCentre M90n Nano IoT has been certified for Windows 10 IoT Enterprise, Microsoft Azure IoT Edge, and Ubuntu. It also supports 4G LTE technology, enabling it to communicate faster with your network.
Safely under lock & key
Each ThinkCentre M90n Nano IoT is hardwired with the Trusted Platform Module (TPM) chipset, an international standard for safeguarding critical data like passwords and encryption keys. In addition, you can physically secure it with a Kensington lock.
Processor family | 8th gen Intel® Core™ i3 |
Processor manufacturer | Intel |
Processor model | i3-8145U |
Processor frequency | 2.1 GHz |
Processor cores | 2 |
Processor boost frequency | 3.9 GHz |
Processor socket | BGA 1528 |
Processor cache | 4 MB |
Processor cache type | Smart Cache |
Processor threads | 4 |
System bus rate | 4 GT/s |
Bus type | OPI |
Processor lithography | 14 nm |
Processor operating modes | 64-bit |
Processor codename | Whiskey Lake |
Thermal Design Power (TDP) | 15 W |
Configurable TDP-up frequency | 2.3 GHz |
Configurable TDP-up | 25 W |
Configurable TDP-down | 10 W |
Configurable TDP-down frequency | 0.8 GHz |
Tjunction | 100 °C |
PCI Express slots version | 3.0 |
Maximum number of PCI Express lanes | 16 |
PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
Number of processors installed | 1 |
Maximum internal memory supported by processor | 32 GB |
Memory types supported by processor | DDR4-SDRAM,LPDDR3-SDRAM |
Memory clock speeds supported by processor | 2133,2400 MHz |
Memory bandwidth supported by processor (max) | 37.5 GB/s |
Internal memory | 4 GB |
Maximum internal memory | 4 GB |
Internal memory type | DDR4-SDRAM |
Memory clock speed | 2666 MHz |
Non-ECC | Y |
Total storage capacity | 128 GB |
Optical drive type | N |
Storage media | SSD |
Card reader integrated | N |
Total SSDs capacity | 128 GB |
Number of SSDs installed | 1 |
SSD interface | NVMe,PCI Express |
SSD form factor | M.2 |
Discrete graphics adapter | N |
On-board graphics adapter | Y |
Discrete graphics adapter model | Not available |
On-board graphics adapter model | Intel® UHD Graphics |
On-board graphics adapter family | Intel® UHD Graphics |
On-board graphics adapter base frequency | 300 MHz |
On-board graphics adapter dynamic frequency (max) | 1000 MHz |
Maximum on-board graphics adapter memory | 32 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter DirectX version | 12.0 |
On-board graphics adapter OpenGL version | 4.5 |
On-board graphics adapter ID | 0x3EA0 |
Ethernet LAN | Y |
Wi-Fi | Y |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
WLAN controller model | Intel Dual Band Wireless-AC 9560 |
Antenna type | 2x2 |
Bluetooth | Y |
Bluetooth version | 5.0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
DVI port | N |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Microphone in | N |
Headphone outputs | 1 |
Combo headphone/mic port | Y |
DC-in jack | Y |
Serial ports quantity | 2 |
Chassis type | mini PC |
Product color | Black |
Volume | 0.55 L |
Placement supported | Horizontal |
Housing material | Metal |
Product type | Mini PC |
Audio chip | Realtek ALC233VB |
Audio system | High Definition Audio |
Password protection | Y |
Password protection type | HDD, Power on, Supervisor |
Trusted Platform Module (TPM) | Y |
Operating system installed | Windows 10 Pro |
Operating system architecture | 64-bit |
Intel 64 | Y |
Enhanced Intel SpeedStep Technology | Y |
Embedded options available | N |
Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
Intel Clear Video Technology | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Intel TSX-NI | N |
Idle States | Y |
Thermal Monitoring Technologies | Y |
Intel® AES New Instructions (Intel® AES-NI) | Y |
Intel® Secure Key | Y |
Intel® OS Guard | Y |
Intel Trusted Execution Technology | N |
Execute Disable Bit | Y |
Intel Flex Memory Access | Y |
Intel Enhanced Halt State | Y |
Intel Software Guard Extensions (Intel SGX) | Y |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
Processor package size | 46x24 mm |
Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
CPU configuration (max) | 1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Intel Identity Protection Technology version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | Y |
Intel Smart Response Technology version | 1.00 |
Intel TSX-NI version | 0.00 |
Processor ARK ID | 149090 |
Intel® Smart Response Technology | Y |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
Intel® Quick Sync Video Technology | Y |
Intel® My WiFi Technology (Intel® MWT) | Y |
Intel® Identity Protection Technology (Intel® IPT) | Y |
Power supply | 65 W |
Certification | MIL-STD-810H |
Sustainability certificates | RoHS, EPEAT Silver, ENERGY STAR |
Width | 7.05" (179 mm) |
Depth | 3.46" (88 mm) |
Height | 1.36" (34.5 mm) |
Weight | 25.4 oz (720 g) |
Display included | N |
Mouse included | Y |
Keyboard included | Y |
