Lenovo ThinkCentre M90n-1 Nano Core™ i3-8145U 2.1GHz 128GB SSD 8GB WIN10 Pro BLACK Keyboard & Mouse
$102
SOLD OUT
We still have a selection of similar available alternatives, click to check them out
Additional information
Aim higher by going smaller
Despite being smaller than an old VHS cassette, the ThinkCentre M90n delivers the same powerful performance as a regular desktop computer, yet uses 15% less energy. By boosting productivity and reducing utility bills, the ThinkCentre M90n is a boon for any business.
Free up your workspace
With a wide choice of easy-to-install mounting and bracket accessories, you can house your ThinkCentre M90n almost anywhere—on a wall, under a desk, or on a shelf. It’s also compatible with various docking solutions, enabling you to have even more ports and flexibility.
Engineered for today & tomorrow
The modular design of the ThinkCentre M90n lets you custom-build the perfect all-in-one PC. As your business needs change, so can your PC without having to replace the display, which can be more costly.
Easy deployment, seamless connectivity
Deploying the ThinkCentre M90n is simple. Just plug a cable into the USB-C port, hook it up to a monitor, projector, or ThinkCentre Tiny-in-One, and you’re good to go. You’ll also enjoy lightning-quick connectivity—for faster data transfers, higher-res displays, multitasking, and much more.
Built-in security
Each ThinkCentre M90n is fitted with the Trusted Platform Module (TPM) chipset, an international standard for safeguarding critical data such as passwords and encryption keys. In addition, the M90n is fitted with a Kensington lock slot, so you can secure your device when working in a public place.
Tested to the max & beyond
Part of the renowned Think family, the ThinkCentre M90n is one tough, durable machine. Able to meet military-specification requirements and other stringent quality checks, it can withstand the harshest of working conditions—from the Arctic cold to desert sand and heat.
Processor family | 8th gen Intel® Core™ i3 |
Processor manufacturer | Intel |
Processor model | i3-8145U |
Processor frequency | 2.1 GHz |
Processor cores | 2 |
Processor boost frequency | 3.9 GHz |
Processor socket | BGA 1528 |
Processor cache | 4 MB |
Processor cache type | Smart Cache |
Processor threads | 4 |
System bus rate | 4 GT/s |
Bus type | OPI |
Processor lithography | 14 nm |
Processor operating modes | 64-bit |
Processor codename | Whiskey Lake |
Thermal Design Power (TDP) | 15 W |
Configurable TDP-up frequency | 2.3 GHz |
Configurable TDP-up | 25 W |
Configurable TDP-down | 10 W |
Configurable TDP-down frequency | 0.8 GHz |
Tjunction | 100 °C |
PCI Express slots version | 3.0 |
Maximum number of PCI Express lanes | 16 |
PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
Number of processors installed | 1 |
Maximum internal memory supported by processor | 32 GB |
Memory types supported by processor | DDR4-SDRAM,LPDDR3-SDRAM |
Memory clock speeds supported by processor | 2133,2400 MHz |
Memory bandwidth supported by processor (max) | 37.5 GB/s |
Internal memory | 8 GB |
Internal memory type | DDR4-SDRAM |
Memory clock speed | 2666 MHz |
Non-ECC | Y |
Total storage capacity | 128 GB |
Optical drive type | N |
Storage media | SSD |
Card reader integrated | N |
Number of storage drives installed | 1 |
Total SSDs capacity | 128 GB |
Number of SSDs installed | 1 |
SSD capacity | 128 GB |
Discrete graphics adapter | N |
On-board graphics adapter | Y |
Discrete graphics adapter model | Not available |
On-board graphics adapter model | Intel® UHD Graphics |
On-board graphics adapter family | Intel® UHD Graphics |
On-board graphics adapter base frequency | 300 MHz |
On-board graphics adapter dynamic frequency (max) | 1000 MHz |
Maximum on-board graphics adapter memory | 32 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter DirectX version | 12.0 |
On-board graphics adapter OpenGL version | 4.5 |
On-board graphics adapter ID | 0x3EA0 |
Ethernet LAN | Y |
Wi-Fi | Y |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
Antenna type | 2x2 |
Bluetooth | Y |
Bluetooth version | 5.0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
DVI port | N |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Microphone in | N |
Headphone outputs | 1 |
Combo headphone/mic port | Y |
DC-in jack | Y |
Chassis type | mini PC |
Product color | Black |
Volume | 0.35 L |
Placement supported | Horizontal |
Housing material | Metal |
Product type | Mini PC |
Motherboard chipset | Intel SoC |
Audio chip | Realtek ALC233VB |
Password protection | Y |
Password protection type | HDD, Power on, Supervisor |
Trusted Platform Module (TPM) | Y |
Operating system installed | Windows 10 Pro |
Operating system architecture | 64-bit |
Intel 64 | Y |
Enhanced Intel SpeedStep Technology | Y |
Embedded options available | N |
Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
Intel Clear Video Technology | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Intel TSX-NI | N |
Idle States | Y |
Thermal Monitoring Technologies | Y |
Intel® AES New Instructions (Intel® AES-NI) | Y |
Intel® Secure Key | Y |
Intel® OS Guard | Y |
Intel Trusted Execution Technology | N |
Execute Disable Bit | Y |
Intel Flex Memory Access | Y |
Intel Enhanced Halt State | Y |
Intel Software Guard Extensions (Intel SGX) | Y |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
Processor package size | 46x24 mm |
Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
CPU configuration (max) | 1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Intel Identity Protection Technology version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | Y |
Intel Smart Response Technology version | 1.00 |
Intel TSX-NI version | 0.00 |
Processor ARK ID | 149090 |
Intel® Smart Response Technology | Y |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
Intel® Quick Sync Video Technology | Y |
Intel® My WiFi Technology (Intel® MWT) | Y |
Intel® Identity Protection Technology (Intel® IPT) | Y |
Power supply | 65 W |
Certification | MIL-STD-810H |
Sustainability certificates | RoHS, TCO, ENERGY STAR |
Width | 7.05" (179 mm) |
Depth | 3.46" (88 mm) |
Height | 0.866" (22 mm) |
Weight | 17.8 oz (505 g) |
Mouse included | Y |
Keyboard included | Y |
Manual | Y |
AC adapter included | Y |
Power cord included | Y |
