ASUS PRIME X570-P AMD Socket X570 AM4 ATX M.2 Desktop Motherboard

$126$151

23 in stock

Don't miss our Special Coupons:
BFTG2110 - $10 (Order above $250)
BFTG2120 - $20 (Order above $600)
BFTG2130 - $30 (Order above $800)
BFTG2140 - $40 (Order above $999)
Offer ends in
About this product
SKU# PRIME X570-P-R | Item# 233178
Warranty: 90 Day Warranty
Condition: Factory Refurbished
Packaging: Generic Box
Notes: Motherboard, I/O Shield, 2x SATA Cables, aftermarket Wi-Fi antennas included *if applicable*, no other accessories. Manufacturer tested and Refurbished.
Minimum order quantity (MOQ): 1
We are not responsible for any typographical and/or photographic errors
Usually ships within 7-10 business days
Special order item, not eligible for return/cancellation. More info
SKU: PRIME X570-P-R Category:

Additional information

Dressed in a professional attire, the Prime X570 series cater to users with serious pursuits in mind, who prefer to put their Ryzen™ processors to more productive use. Prime X570, known for its all-around specs and ASUS signature features, includes a wide range of tuning options for accessible performance.

Foundation of your build
Hosting the latest Ryzen processor with increased number of cores and bandwidth, the Prime X570 series is ready for action with stable power, intuitive cooling and flexible transfer options. It provides all the fundamentals to increase your everyday productivity.

Power delivery enhancements
The 3rd Gen AMD Ryzen™ processors boast more cores and bandwidth, demanding more power than typical desktop CPUs. Prime X570-P is geared up for the demands of these high-core-count processors, offering a stable power to ensure optimal performance.

ProCool connectors
It augments the motherboard’s link to the PSU with 8+4 pin connectors that pass 12V power directly to the processors. Based on our ProCool design, these jacks use solid pins that can handle more current than hollow-pin connectors.

Dual PCIe 4.0 M.2 slots
Achieve speed with onboard M.2
With PCIe 4.0 M.2 Slot supports up to 22110 and provide NVMe SSD RAID support for an incredible performance boost. Create a RAID configuration with up to two PCIe 4.0 storage devices to enjoy the fastest data-transfer speeds on the 3rd Generation AMD Ryzen platform.

SafeSlot
Protect your Graphics Card Investment

SafeSlot is the PCIe slot reinvented by ASUS and engineered to provide superior retention and shearing resistance. Manufactured in a single step using a new insert-molding process, SafeSlot integrates the slot with fortifying metal for an inherently stronger slot, which is firmly anchored to the PCB through additional solder points.

ASUS OptiMem
Proprietary Memory Design

ASUS OptiMem memory trace layout unleashes the full performance potential of AMD’s Infinity Fabric architecture by enabling higher memory frequencies and lower latencies.

USB 3.2 Gen 2
Ultimate-speed 10Gbps with USB 3.2 Gen 2 onboard

With backward-compatible USB 3.2 Gen 2 Type-A™, you’ll experience ultimate connection flexibility and blazing data-transfer speeds of up to 10Gbps.
*The USB ports under the LAN port require a 3rd Gen AMD Ryzen processor for USB 3.2 Gen 2 speeds.

LANGuard
Pumped-up throughput, 2.5X higher surge tolerance

ASUS LANGuard is a hardware-level networking protection that employs signal-coupling technology and premium anti-EMI surface-mounted capacitors to ensure a more reliable connection and better throughput.

Cooler by design
Prime X570-P features the most comprehensive cooling controls ever, configurable via Fan Xpert 4 or the UEFI BIOS.

Active Chipset Heatsink Solution
Dedicated cooling for unthrottled transfers
PCIe 4.0 provides twice the bandwidth for data flowing through the chipset, which creates more heat than the previous generation. The Prime X570-P features an actively cooled heatsink to prevent throttling during sustained transfers.

Outstanding audio
Realtek codec and unique design features for pristine, powerful audio
Prime X570-P utilize a unique audio codec designed in close collaboration with Realtek — the Realtek S1200A. It also features an unprecedented 108dB signal-to-noise ratio for the stereo line-out and a 103dB SNR for the line-in, providing pristine audio quality.

The Prime X570 series feature software and firmware controls that make performance accessible to anyone. Prime X570 series also include options allowing you to personalize your build, and helping you to tune your rig to perform the way you want it.

Armoury Crate
Armoury Crate is a new software utility designed to give you centralized control of supported products. From a single intuitive interface, Armoury Crate allows you easily customize RGB lighting and effects for every compatible device in your arsenal. The software also provides control of settings for ASUS product, including keyboard and mouse preferences. Armoury Crate even features dedicated product registration and highlight to help you stay in touch with the ASUS community.

Aura Sync RGB headers
Outshine the competition

A well-tuned enthusiast system deserves a matching aesthetic. ASUS Aura Sync offers full lighting connected via the motherboard’s RGB headers, with a variety of functional presets for external LED strips. And it can all be synced with an ever-growing portfolio of Aura-capable ASUS hardware.

Addressable Gen 2 RGB header
Prime X570-P’s Addressable Gen 2 RGB header is now capable of detecting the number of LEDs on second-gen addressable RGB devices, allowing the software to automatically tailor lighting effects to specific devices. The new headers also offer backward-compatibility with existing Aura RGB gear.

Brighten Up Your Build
LED-illuminated control for PCH

Built-in LED lighting options illuminate your build in a variety of eye-catching styles.

Processor manufacturerAMD
Processor socketSocket AM4
Compatible processor series2nd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 3, 2nd Generation AMD Ryzen™ 5, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9
Maximum number of SMP processors1
Supported processor socketsSocket AM4
Supported memory typesDDR4-SDRAM
Number of memory slots4
Maximum internal memory128 GB
Memory slots typeDIMM
Memory channelsDual-channel
ECCY
Supported memory clock speeds2133,2400,2666,2800,2933,3000,3200,3400,3466,3600,3733,3866,4000,4133,4266,4400 MHz
Unbuffered memoryY
Supported storage drive interfacesM.2,PCI Express 4.0,SATA III
RAID supportY
RAID levels0,1
Parallel processing technology support2-Way CrossFireX
Maximum resolution4096 x 2160 pixels
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of SATA III connectors6
S/PDIF out connectorY
Front panel audio connectorY
Front panel connectorY
ATX Power connector (24-pin)Y
Number of EATX power connectors1
CPU fan connectorY
Number of chassis fan connectors3
Number of COM connectors1
TPM connectorY
12V power connectorY
RGB LED pin headerY
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
PS/2 ports quantity1
HDMI version1.4b
Headphone outputs3
Wi-FiN
Ethernet LANY
Ethernet interface typeGigabit Ethernet
LAN controllerRealtek RTL8111H
Wake-on-LAN readyY
BluetoothN
Component forPC
Motherboard form factorATX
Motherboard chipset familyAMD
Motherboard chipsetAMD X570
Audio output channels8 channels
Audio chipRealtek ALC S1200A
Windows operating systems supportedWindows 10 x64
PCI Express x1 slots3
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots2
BIOS typeUEFI AMI
BIOS memory size256 Mbit
ACPI version6.2
Clear CMOS jumperY
System Management BIOS (SMBIOS) version3.2
Width12" (305 mm)
Depth9.61" (244 mm)
Cables includedSATA
Drivers includedY
